Noosa Cat 4100

The 4100 Series is 12.26m (40' 3") of unstoppable, high performance offshore boating in a class of its own.

Designed as a true multi-functional vessel, the big 4100 Series cruises in the high 20's with just twin 6 cylinder, Volvo Penta Diesels - and easily runs to over 30 knots with suitable power.

Available with shaftdrive or sterndrive, standard or extended cabin, fully enclosed flybridge, and a standard of fit-out tailored to the customer's precise needs, ensure the superb Noosa Cat 4100 is perceived as an outstanding investment for a wide range of commercial or leisure applications.

Pre-delivery offshore test run in Puma Energy's new 4100 Series Ferry (30-passenger) powered by 2 x @Mercury's Diesel TDI 335hp V8 Bravo 3 sterndrives. Top Speed Offshore = 35knots/65kph/42mph, Optimal Cruise Speed = 41kph/22knots, Range 652km/352nm, Acceleration (0 - 20 knots) in 6.5 sec (weight as tested 7,330kg).

Water Tests + Performance Bulletins

Modern Boating 4100 Flybridge Water Test
Australian Power Boat 4100 Water Test
Aus Boat Mag 4100 IPS Water Test
Fisherman & Boatowner IPS Water Test

Mercruiser TDI 335hp V8 (Search & Rescue) Performance Bulletin
Mercruiser TDI 335hp V8 (Passenger Ferry) Performance Bulletin


4100 Specifications

Model Configurations Standard Cabin / Standard Cabin + Flybridge / Extended Cabin / Extended Cabin + Flybridge
Recommended Base Horsepower 2 x 200hp
Moulded Length 11.10m |  36' 5"
Shipping Length 12.26m |  40' 3"
Beam 3.50m | 11' 6"
Hull Draft at Rest  0.52m | 1' 8"
Base Displacement (App.) 6,800 kg | 15,000 lb
Cockpit length (inside or clear space) 4.39m | 14' 5"
Cockpit width (inside or clear space) 2.72m | 8' 11"
Maximum Recommended Power Stern Drive 2 x 500hp
Maximum Recommended Power Shaft Drive 2 x 500hp
Minimum Recommended Power Stern Drive 2 x 260hp
Minimum Recommended Power Shaft Drive 2 x 260hp
Base Berth Plan 2 x Double Berths
Fuel Tanks Standard (App.) 2 x 540 litres | 2 x 143 gallons - larger capacity available
Water Tanks (App.) 1 x 110 to 200 litres | 1 x 29 to 53 gallons
